Eol Tester

The AVL EoL Tester is a compact test solution, consisting of either one or two cabinets. It can be used to perform 100% routine testing as well as testing of field returns.

Keyfacts

Product Phase

Production

UUT

Inverter

Phases

3
6

Your Challenge

The time span between a fully developed inverter and the start of series production is constantly decreasing. Test solutions are needed in which adaptations to the UUT’s hardware and software can be implemented in the shortest time possible. Also, end-of-line tests need to be adapted to the cycle time of production. At the same time the test equipment needs to run in robust and fail-safe operation. Therefore, flexible solutions are needed to fulfill all customer specific requirements

Our Solution

The AVL EoL Tester is a compact test solution, consisting of either one or two cabinets. It can be used to perform 100% routine testing as well as testing of field returns. Test sequences are implemented according to customer specific requirements. Precise measurements and interpretation of the test results are guaranteed. The documentation of production data is included.

Highlights

  • Compact, modular test setup
  • Simple test configuration
  • Minimal installation effort
  • Fully automatic testing of inverters (3-phase or 6-phase)
  • Customer specific sequence controller
  • Testing at full current and voltage according to customer requirements
  • Energy-saving and cost-effective purely inductive load
  • Fully comprehensive test system including calibration, logging, evaluation of measured values or IO/NIO

Fault Behaviour and Safety Tests

Game changer motor emulation: E-motor faults can be very easily, reproducibly, and automatically conducted with a test system with an e-motor emulator, since in this case the e-motor is simply being modelled by software. A further advantage of this test layout is the extended protection for the drive inverter because the emulator limits the phase current to a previously defined maximum value. This ensures that the unit under test is never damaged if the inverter displays undesirable behaviour during the fault test.

More Test Cases

Customer Voice

“AVL’s EoL Tester is compact, robust, cost-efficient and reliable. At the same time it ensures that all relevant test requirements throughout the product production phase are met. The solution provided by AVL SET makes testing quick and easy.” *

*We are aware that you would like to know which customer voice you have just heard. As we are bound to non-disclosure agreements, we hope for your understanding that we are not always able to put references on our website. Please get in touch and we will be happy to tell you more about our solutions and specific test cases.
